Description
MOHR cutting machines (in the graphics industry also known as guillotine or paper cutter) are durable, programmable cutters with hydraulic drive units.
Both, the company and the operator value not only the uncomplicated operation, but also the long service life of the cutting machine. The unique cutting precision is obtained by a sturdy construction and direct measurement system.
MOHR 80 (31.5") ECO:
The machine is operated via an ergonomically arranged control panel with 5.5" monochrome display and extra low-profile keyboard. Repeat sequences can be saved in one of 198 available memory positions and even be adapted at any time.
MOHR 80 (31.5") PLUS:
Operation via 18.5" touch-screen display. There are 1998 memory positions available for repeat cut sequences.
Cutter MOHR 80 (31.5") ECO
Sturdy, programmable cutter with hydraulic drive and 5,5“ monochrome display.
Customer benefits
• Extensive programming options with a memory capacity of 198 programs
• Easy knife change with automatic interruption in the lower dead end and knife fine adjustment from the front
• Machine frame with optimized stability for optimum absorption of cutting forces and greatest cutting accuracy
• Minimal maintenance requirements due to the use of novel materials
Description of the machine
The cutter MOHR 80 is designed for one-shift operation. The precise and gentle swing cut is carried out hydraulically. Thus, the time of the knife spent in the lower dead end can be adapted to the material. The ultra-smooth stainless table surface equipped with air jets allows an easy handling of the material. Within a wide setting range the clamping pressure can be adjusted infinitely to each cutting material by means of a turning knob with scale. Bright LEDs mark the cutting line clearly visible for the operator. The operation of the machine is done via an ergonomically positioned control panel with 5.5’’ monochrome display and additional membrane keypad. Recurring cutting sequences can be memorized (memory capacity 198 programs) and adapted at any time. The creation of the cutting programs is done either manually or menu-driven and intuitively via block programming. To optimize the cutting quality the pre-clamping time can be adjusted according to the material.
Technical data
Cutting width 800 mm | 31.50 in
Feeding depth 800 mm | 31.50 in
Feeding height max. 100 mm| 3.94 in
Clamp pressure min. 180 daN | 397 lbs
Clamp pressure max. 2,700 daN | 5,952 lbs
Backgauge speed on return way (0 - ...) 130 mm/sec | 5.12 in/sec
Smallest cut, automatically, without false plate 15 mm | 0.59 in
Smallest cut, automatically, with false plate 50 mm | 1.97 in
Dimensions (w × d × h) 1,500 × 1,970 × 1,500 mm | 61.02 × 77.56 × 59.06 in
Weight 900 kg | 1,984 lbs
Cutter MOHR 80 (31.5") PLUS
Sturdy, programmable cutter for integration into the digital workflow with 18.5” touch-screen displayand process visualization.
Customer benefits
• Process visualization for the graphical display of the material handling to minimize the risk of errors
• Machine frame with optimized stability for optimum absorption of cutting forces and greatest cutting accuracy
• Minimal maintenance requirements due to the use of novel materials
Description of the machine
The cutter MOHR 80 is designed for one-shift operation. The precise and gentle swing cut is carried out hydraulically. Thus, the time of the knife spent in the lower dead end can be adapted to the material. The ultra-smooth stainless table surface equipped with air jets allows an easy handling of the material. Within a wide setting range the clamping pressure can be adjusted infinitely to each cutting material by means of a turning knob with scale. Bright LEDs mark the cutting line clearly visible for the operator. The operation of the machine is done via an ergonomically positioned 18.5’’ touch-screen display. Recurring cutting sequences can be memorized (memory capacity 1,998 programs) and adapted at any time. With the process visualization the handling of the material is displayed graphically and so the risk of errors significantly downsized. To optimize the cutting quality the pre-clamping time can be adjusted according to the material.
Technical data
Cutting width 800 mm | 31.50 in
Feeding depth 800 mm | 31.50 in
Feeding height max. 100 mm| 3.94 in
Clamp pressure min. 180 daN | 397 lbs
Clamp pressure max. 2,700 daN | 5,952 lbs
Backgauge speed on return way (0 - ...) 130 mm/sec | 5.12 in/sec
Smallest cut, automatically, without false plate 15 mm | 0.59 in
Smallest cut, automatically, with false plate 50 mm | 1.97 in
Dimensions (w × d × h) 1,500 × 1,970 × 1,500 mm | 61.02 × 77.56 × 59.06 in
Weight 900 kg | 1,984 lbs
