The Intec ColorCut FB575 flatbed cutter is the entry-level model, featuring the same striking design DNA as the rest of the new generation 75 series.
This is a high-specification B3 cutting table device with a compact footprint. The cutting table accommodates up to one SRA3 (Tabloid Plus) sheet and is targeted for light production work.
- B2+ table takes SRA2 – or 2 x SRA3 and smaller
- No dies required – cut and crease any shape on demand
- Dual-tool head for same time cutting (1.2kgf) and creasing (1.5kgf)
- Blistering performance of up to 1,200mm/second
- Unparalleled accuracy using latest servo technology
- Cuts mixed jobs on table using QR coded auto job recognition to automatically retrieve associated cut files
- Cuts through up to 1,000 micron/800gsm paper/card, softboards and films to any shape
- Kiss-cuts perfect sheet labels of any shape
- CCD Video Camera driven to accurately follow vector cut/crease lines drawn in Adobe® Illustrator® & CorelDRAW®
- Vacuum suction media hold down table for even the smallest of items
- Effective cutting area 490 x 735mm
- Cut mixed job sheets for increased productivity on the bed, at the same time!
- Complete with dedicated ColorCut Pro cutting & creasing software, with Adobe® Illustrator® or CorelDRAW® plugins
- Sheet Labels
- Sheet card
Maximum Media Area: 22.83” x 31.49”
Cutting Area: 18.89” x 28.14”
Media Handling: 750W vacuum suction
Tools: 2 tool positions
Maximum Cutting Depth: 1000 micron/800 gsm
Maximum Speed: Fast: 1200mm/s; Standard: 960mm/s; HD: 750mm/s
Custom Stock Status: Ships 7-10 days
